SC100/100 Construction Hoist
Twin Cage Building Elevator for Heavy-Duty Vertical Transport
The SC100/100 Twin Cage Construction Hoist is a heavy-duty gear-rack driven building elevator manufactured by Guangxi Gongkai Heavy Industry (GKZG). Designed for efficient vertical transportation of materials and personnel in high-rise construction projects, this robust twin-cage system delivers a combined rated capacity of 2,000 kg with each cage capable of carrying 1,000 kg or 12 workers independently.
Roted load (kg) | 2×1000 |
|---|---|
Roted speed(m/min) | 0~28 |
Motor power(KW) | 2×(1×13) |
Frequency converter power(KW) | 2×18 |
Gear ratio | 1:20 |
Rated curent(A) | 2×28 |
Safely device type | SAJ30-1.2 |
Cage size (L*W*H) | 3.0m×1.5m×2.1m |
Total moss of coge(kg) | 2×1050 |
Size of mast section | 650mm×650mm×1508mm |
Most Secton Nerght (kg） | 150 |
Mox fifing eight(m) | 150 |
Since 2005, GKZG has been a trusted name in construction hoist manufacturing, combining advanced gear-rack drive technology with patented safety innovations. The SC100/100 exemplifies our commitment to engineering excellence, featuring a progressive anti-fall safety device (national patent technology) that sets new standards for operator protection in demanding construction environments across Southeast Asia, Central Asia, and beyond.
Built for reliability in industrial and civil construction, bridge engineering, chimney installation, and shipyard applications, the SC100/100 handles the toughest jobs with consistent performance day after day.
